Product Description
This safety projector bundle consists of an ECO Spot C60PCE LED Gobo Projector configured with a virtual sign of your choice. This is for a 3′ to 5′ sign size.
The C60PCE is the most popular version of our PCE-Series projectors. It is designed for industrial, dusty or wet environments. It has no moving parts such as fans or motors.
Please select the sign you would like, the brightness level, your required projection size, and mounting distance above. Based on these values, we will select the most effective projection lens combination for you.
The C60PCE is designed for industrial, dusty or wet environments. It has no moving parts such as fans or motors. Instead it relies on a huge oversized heat sink that is easy to clean. UL/cUL Certified for industrial and wet environments – certificate number – E4993665.
Features
- UL/cUL rated for wet environments (2019 models) E4993665
- Passive Cooling – no fans or motors.
- Ideal for dusty and wet industrial environments.
- Long service intervals.
- Wide line voltage range.
- 30,000 hours bulb life – never exchange a bulb over the life of the projector.
- Quality optical system with interchangeable Lenses.
- Full Aluminum Housing
- Takes std. D-size gobos.
Specifications
Projector
- Order Code: ES-C60PCE
- Power Supply: 95V-265V, 50-60GHz, 70W
- Ambient Temp. Range: -22°F to 140°F (-30°C to 60°C)
- Can be used in-/and outdoors Exterior Version
- UL/cUl Certification UL/cUL rated for wet environments (2019 models) E4993665
Optical
- Lamp: 60W LED, 30,000h rated bulb life
- Projection Lens Included: yes, choose from options below
- Available Lenses: Narrow: f=140mm/10°, Semi-Narrow: f=100mm/15°, Medium: f=70mm/20°, Ultra-Wide: f-28mm/45° (Max ID with this lens is 23mm)
- Effective Luminous Flux: 2,400lm
- Color Temperature (Kelvin): 6,000k +/-500k
- Dimmable: Yes, with trimmer
Dimensions
- Gobo Size: D-Size (OD53mm, ID25mm) Max. thickness: 4mm
- Total Length: 15 – 18” (incl. lens)
- Height: 11”
- Width: 10.5”
- Weight: 14 lbs
Safety Projector Bundle Contents
- Power Cord
- Test Gobo
- Spare Gobo Retaining Ring
- Integrated Gobo Mounts
- User Manual
